Specification Parameter List
| Model | Capacity (m3/min) | Air Connection | Dimensions (mm) | Weight | ||
|---|---|---|---|---|---|---|
| L | W | H | ||||
| HDR-004 | 0.4 | G1/2” | 105 | 76 | 250 | 2 |
| HDR-007 | 0.7 | G1/2” | 105 | 76 | 250 | 2 |
| HDR-015 | 1.5 | G3/2” | 105 | 76 | 250 | 2 |
| HDR-24 | 2.4 | G1” | 105 | 76 | 250 | 2 |
| HDR-35 | 3.5 | G1-1/2” | 105 | 76 | 310 | 2 |
| HDR-24 | 2.4 | G1” | 105 | 76 | 250 | 2 |
| HDR-35 | 3.5 | G1-1/2” | 105 | 76 | 310 | 3 |
| HDR-60 | 6.0 | G1-1/2” | 137 | 99 | 400 | 4 |
| HDR-90 | 9.0 | G1-1/2” | 137 | 99 | 425 | 5 |
| HDR-120 | 12.0 | G2” | 137 | 99 | 620 | 10 |
| HDR-150 | 15.0 | G2” | 135 | 108 | 750 | 12 |
| HDR-240 | 24.0 | G2-1/2” | 148 | 125 | 920 | 15 |
| HDR-360 | 36.0 | DN150 | 475 | 135 | 1113 | 137 |
| HDR-450 | 45.0 | DN150 | 475 | 135 | 1265 | 140 |
| HDR-600 | 60.0 | DN150 | 520 | 157 | 1315 | 180 |
| HDR-900 | 90.0 | DN200 | 590 | 157 | 1315 | 200 |
| HDR-1200 | 120.0 | DN250 | 660 | 157 | 1350 | 250 |
| HDR-1500 | 150.0 | DN300 | 700 | 189 | 1350 | 265 |
| HDR-1800 | 180.0 | DN350 | 980 | 235 | 1350 | 300 |
